A "Powerhouse" sums this wood heater up. The Equinox was built to warm your home. This woodstove has been designed to heat even the largest of spaces - while keeping the high-end design and style of our HearthStone Select Collection of soapstone stoves.
4.0 cubic foot firebox
Large firebox accepts 25” logs through the front door, or through the easy-loading side door. Front and side doors provide maximum loading ease, and increased fuel efficiency.
Single air-intake lever/stove control
Stove operation is easy; performance more consistent.
Open and close ash grate and removable ash drawer
Easy, clean ash removal; pan can be removed while fire is burning.
Unmatched fire viewing
Air entering the firebox through the stove’s secondary air tubes ignites the gases rising off the burning wood. The resulting light and flames provide dazzling fire viewing, even when the fire is burning at a low rate.
Non-catalytic combustion system
Clean burning, complete combustion provides more heat from less wood, greater efficiency, reduced smoke and creosote build-up.
8” reversible flue collar
Flexible installation; stove can be installed as a freestanding unit, or as a hearth stove.
Outside air adapter (optional)
Improved efficiency in today’s newer, “airtight” homes; reduces cold drafts along the floor.
Rear heat shield (optional)
Allows more placement options; stove can be installed closer to a wall because clearance requirements are reduced; creates a convection passageway between shield and back of stove to allow optional fan to circulate air through the house more effectively.
Fan with built-in thermostat and rheostat (optional)
Helps spread heat evenly throughout home; fan only operates when stove is at a significant heat level. The rheostat controls fan speed. Use of rear heat shield is required. Fan moves air up to 200 CFM.
Allows for open door fire viewing.
Side door lock kit (optional)
Use optional lock kit to reduce side hearth clearance from 16” to 3 1/8”.
Heats up to 3,500 sq. ft.
Burn Time Up to 12 hours
Heat Life Up to 16 hours
Size 120,000 BTUs
EPA Rating 3.0 grams per hour
Efficiency 82% (Low Heating Value)
Width 33 5/8"
Height (includes flue collar) 30 5/8 "
Maximum Log Length 25"
Firebox Capacity 4.0 cubic feet
Flue Diameter 8"
Flue Exit Top or Rear
Flue Exit & Diameter Top or rear exit 8" flue collar
Ash Pan Yes
Actual Weight (lbs.) 689
Alcove Certified Yes
Optional Blower Kit Yes
Mobile Home Certified Yes
Clearances (With single wall pipe & no rear heat shield)
Clearances (With double-wall pipe & rear heat shield)
Corner 13 1/2 "
Minimum Size (US) 48" W x 41 1/2 " D
Minimum Size (Canada) 143 cm x 122 cm
Read 1 ReviewsWrite a Review
REVIEW SNAPSHOT®by PowerReviews
- Easy to light
- Good power output
- Great looking
- Great temperature control
- Ash pan handle wear quick
- Difficult to clean
- Draft control sticks
- Heavy / bulky
Reviewed by 1 customers
Displaying reviews 1
- Great temperature control
- Great Looking
- Easy to Light
- Ash Pan Handle Wear Quick
- Draft Control Sticks
- Difficult to Clean
The stove is great dont get me wrong. The stove is three years old and the ash pan handle is worn thru but the company is giving me a new one under my FIVE year warranty. After that I'm stuck paying. It is hard to get in all the cracks to clean in side the fire box and the outside in between the stones. but it does put out some hot heat and wood last for a while. would buy again.
